Dual-Head Spouted Pouch Filling and Capping Machine

I. Equipment Features

1. **Applicability:** Suitable for pouch-packaged products in the daily chemical and food industries—such as laundry detergent, shampoo, jelly, milk, and similar items.

2. **Simple Operation:** Features digitized machine setup; for pouches of the same size, parameters can be saved, requiring only an adjustment to the product filling volume for subsequent runs.

3. **High Efficiency:** Offers rapid filling speeds and excellent operational stability. Each filling nozzle is independently controlled by a dedicated servo motor, ensuring high filling precision.

4. **Easy Cleaning:** The gear pumps, material storage tank, and filling heads utilize clamp-style connections; this allows for localized disassembly and cleaning without the need for tools. Additionally, an automatic cleaning function is accessible via a dedicated button on the main control screen.

Equipment Operation Mode: 1 Person for Bag Hanging — Automatic Filling — Manual Cap Placement — Automatic Capping; (Operated by 1 person)

Applicable Capacity: 50–3000 g

Equipment Speed: 15–35 bags/minute (depending on the filling volume)

For example: Approx. 15–18 bags for 2000 g; approx. 20–25 bags for 1000 g; approx. 30 bags for 450 g.

Equipment Filling Accuracy: ±0.5% (e.g., 100 ±0.5)

Functional and Structural Description:

1. Bag Feeding Method: Manual bag hanging

2. Filling Method: Servo-driven magnetic gear pump quantitative filling (self-priming)

3. Cap Feeding Method: Automatic cap feeding via cap chute; manual cap placement or automatic cap placement via vibrating bowl feeder

4. Capping Method: Servo-driven capping with precise, adjustable torque

5. Bag Discharge Method: Rotary automatic bag discharge
