Dual-Head Servo Capping Machine (Linear Type) LPE-SCM02-L
The entire machine features servo control with adjustable and controllable torque, ensuring precise and error-free capping.

Product Details


1. The entire machine features servo control with adjustable and controllable torque, ensuring precise and error-free capping.

2. Mimicking the human hand, it employs a precise, parallel gripping mechanism to handle caps—preventing cross-threading, tooth misalignment, and damage to the caps—thereby ensuring smooth and accurate capping.

3. Molds can be swapped out in just one minute, effortlessly resolving the challenges associated with handling a wide variety of cap and bottle sizes.

4. Utilizing a world-renowned control system—specifically a Siemens PLC from Germany—alongside German SICK sensor technology, the equipment guarantees stable operation and ultra-high-precision capping during production. With a capping accuracy rate reaching 99.99%, it ensures both product quality and operational safety.

5. Highly versatile, the machine accommodates bottles of various specifications, shapes, and materials, thereby meeting diverse production requirements and significantly reducing operating costs for the user.

6. Featuring a high degree of automation—including automatic cap feeding and capping—the system substantially boosts production efficiency and lowers operational costs for the business.

7. Maintenance costs are low; the equipment features a simple mechanical structure that is easy to operate and maintain. Its convenient serviceability minimizes production losses typically associated with downtime for repairs.

Product Parameters

1. Cap Feeding Method: Pneumatic gripper pick-and-place.

2. Cap Sorting Method: Cap elevator belt sorting; requires changing guide rails and bottle-clamping/cap-feeding assemblies for different cap types.

3. Cap Feeding Speed: 600–9,600 caps/hour.

4. Capping Method: Servo-controlled, torque-limited gripper-style capping.

5. Capping Speed: 1,500–2,500 bottles/hour.

6. Total Power: 1.4 kW.

7. Power Supply: AC 220V, 50/60 Hz.

8. Operating Air Pressure: 0.5–0.6 MPa.

9. Air Consumption (Compressed Air): 170 L/min.

10. Applicable Range: Cap diameter 20–120 mm; Container/Bottle height 30–250 mm.

11. Conveyor Belt Height: 850 mm.

12. Main Exterior Material: 304 Stainless Steel.

13. Equipment Dimensions: Length 2424 × Width 1842 × Height 2190 mm (approx.).

14. Wooden Crate Dimensions: Main Unit: Length 1240 × Width 890 × Height 1760 mm; Cap Elevator: Length 2240 × Width 810 × Height 1140 mm.


Product Configuration

配置(标准配置,实际生产会有部分调整,按最终生产为准)

序号
No.

配件名称
Part name

品牌
Brand

产地
Origin


1

程序控制器
PLC

西门子
SIEMENS

德国
Germany

PLC


2

触摸屏
Touch screen

西门子
SIEMENS

德国
Germany

Touch screen


3

光电传感器
Photoelectric sensor

西克
SICK

德国
Germany

Photoelectric sensor


4

接近传感器
Proximity detector

松下
PANASONIC

日本
Japan

Proximity detector


5

继电器
Relay

西门子
SIEMENS

德国
Germany

Relay


6

保险底座
Fuse base

施耐德
SCHNEIDER

法国
France

Fuse base


7

断路器
Breaker

施耐德
SCHNEIDER

法国
France

Breaker


8

按钮
Button

施耐德
SCHNEIDER

法国
France

Button


9

气动元件
Pneumatic component

亚德客
SYMTECH/AIRTAC

意大利/台湾
Italy/Taiwan

Pneumatic component


10

旋盖伺服电机
Servo motor

汇川
INOVANCE

中国
China

Servo motor


11

开关电源
Switch power

台达
DELTA

台湾
Taiwan

Switch power


12

输送带电机
Conveyor belt motor

台邦
VTV

台湾
Taiwan

Step motor
