The fully automatic capping machine is an improved design based on internationally advanced models. It features fast capping speed, high pass rate, and easy operation. It is suitable for capping various bottle shapes in the food, pharmaceutical, daily chemical, pesticide, and cosmetic industries. The machine integrates cap feeding, bottle clamping, conveying, and capping; it boasts a high degree of automation, good stability, and convenient adjustment. No spare parts are needed when changing bottle shapes or caps; only adjustments are required (automatic capping can be performed if equipped with a capping machine). Optional accessories can be selected based on actual needs.

Operating mode:

The device has four sets of wheels. The first set of wheels rotates in reverse to align the cap threads with the bottle neck threads. The second, third, and fourth sets of wheels rotate clockwise to screw the cap on!

Features of automatic capping machine:

1. Constructed from stainless steel and lightweight, anti-oxidation aluminum profiles.

2. Highly compatible with various common bottle caps. Easy to operate.

4. Excellent flexibility; adjustable to accommodate bottle height and cap size; tightness can be customized to customer requirements.

5. Capping rollers are made of wear-resistant silicone.

6. Equipped with automatic lifting function for easy bottle type changes.

7. Can be integrated into filling production lines.

Technical Parameters

1. Capping Speed: 3600-6000 bottles/hour (depending on bottle size and cap compatibility)

2. Power Supply: 220V 50-60Hz

3. Machine Power: 2KW

4. Applicable Bottle Diameter Range (mm): 30-210mm

5. Applicable Cap Diameter Range (mm): 20-150mm

6. Applicable Product Height Range (mm): 80-280mm

7. Net Weight: 300KG Gross Weight: 360KG

8. Machine Dimensions: Length 2000 * Width 900 * Height 1600mm
